To improve jaw crusher production efficiency with coup

In order to ensure the jaw crushers with high productivity, the qualified yield, low power consumption and stable long-term ability to run, it is necessary equipment correct operation and reasonable and timely maintenance.

Jaw crushers maintenance work is mainly focused on the aspects of lubrication, tightening, adjustment and cleaning.

Each of the friction surfaces of the jaw crushers during operation should be promptly lubricated, thereby ensuring the long-term normal operation of the crusher machine. Therefore, each slide parts lubrication must pay special attention to, otherwise it will cause a major accident. The complex pendulum crushers the moving jaw bearing and thrust plate and the Order of the pad with lubrication, general dry oil lubrication. In cases where the winter dry oil solidification may, in which the addition of 20% (weight) of automotive lubricants lubrication. The lubrication of the contact surfaces must be fully and evenly. But the full extent of oil in the Rolling Block should not exceed 50% to 70% of its volume. Run usage can fill oiling once every 1 to 2 days. Each quarter is best for lubricants, bearings thorough cleaning after check. Practice has proved that the life of the schedule to fill and replace lubricants prolong bearing parts.

Yifan machinery lubrication system is generally cooler by the oil pump, filter, fuel pressure regulators, fuel tank, tubing, instrumentation devices. When excessive pressure is too high or the oil flow, fuel pressure regulators to adjust. The traffic in the normal lubrication process must be appropriate. The lubrication system back to the oil temperature does not exceed 60 ° C tank temperature should be controlled at 35 ° C to ambient temperature. When the oil temperature is too high, you should take water cooling measures. The water pressure should be lower than the oil pressure of 0.5 atm. 0.40 Atmospheric pressure pressure difference before and after the oil filter, clean the filter. Thin oil lubrication oil (30 to No. 50 machine oil) every 3 to 6 months in normal operating conditions for a replacement. While thoroughly cleaning the fuel tank with kerosene and other sliding parts, parts. Oily cleaning to ensure the entire lubrication system unimpeded. The timing use artificial lubrication of the parts, should pay attention to timely, adequate, correct lubrication.

Lubrication is only one aspect of the jaw crushers, in the case of the normal functioning of the jaw crushers, we want to ensure the bearing temperature should not exceed 35 ° C, the maximum temperature rise to no more than 70 ° C. The last to be done in the process of using a jaw crushers crushing cavity material clogging caused by the parking should be immediately shut the motor material must first be cleared, and then restart. The above method is to increase the efficiency of the jaw crushers, improve work efficiency, eliminating the need for an unnecessary expenditure.
